Spells

Every Charms transaction contains a spell: Charms-related metadata added to the blockchain transaction (similar to Runes’ runestones).

Spells are client-side validated, meaning that the users choose to interpret or ignore them. If they choose to interpret them, they can use charms — similar to Ordinals and Runes interpreted by ord.

A spell is said to be correct if and only if all of these are true:

• it is successfully parsed and interpreted
• makes sense for the transaction (e.g., doesn’t produce more Charms outputs than there are Bitcoin outputs)
• has a valid proof

Correct spells can mint, burn and transfer tokens. The practical effect of a spell is that tokens are considered parts of the enhanced transaction outputs.

Incorrect spells are ignored.

Double-spending is prevented by Bitcoin.

What Spells Look Like

Spells create and transform charms via Bitcoin transactions.

A spell is stored in an OP_RETURN output of the transaction:

OP_RETURN
  OP_PUSH "spell"
  OP_PUSH $spell_and_proof

where:

• OP_PUSH "spell" is a marker identifying the output as a Charms spell.
• OP_PUSH $spell_and_proof — CBOR-encoded (NormalizedSpell, Proof) tuple (see v11.0.1 source). The proof is a Groth16 proof attesting to the correctness of the spell.

Logical Structure of a Spell

Here is an example of a spell that sends an NFT and some fungible tokens, and also mints some tokens:

version: 11
tx:
  ins:
    - 33027a870a0f8c7b3d3114d970b6e67d11b32316ad5b6c58bdc7e0d8e77f7e6a:1
    - 92077a14998b31367efeec5203a00f1080facdb270cbf055f09b66ae0a273c7d:0
  outs:
    - 0:
        ticker: TOAD
        remaining: 30160
      1: 42
    - 2: 69420
  coins:
    - amount: 1000
      dest: 2f7e10b8f6e2089b5bb5dcce96e8dd49ca01012f6506af0fe7bf5d2f2f5db531
    - amount: 1000
      dest: 009fb48961bca8ec68f01ec882f7ec0dc7dc5cc6bcf4ad154f129ea2338f6cd1
app_public_inputs:
  n/f54f6d40bd4ba808b188963ae5d72769ad5212dd1d29517ecc4063dd9f033faa/7df792057addc74f1a6ca23da5b8b82475a7c31c3a4d45266c16a604c62eba4c:
  t/7e7e5623a8b44556021171f533a3404b009e7c66edd5a47362c8e54c54a6e058/b25ddd68cd441a2bb0f7113abaaef74983c4e01fc66c7465e1f18363fc80454d:
  t/f54f6d40bd4ba808b188963ae5d72769ad5212dd1d29517ecc4063dd9f033faa/7df792057addc74f1a6ca23da5b8b82475a7c31c3a4d45266c16a604c62eba4c:

In this example we have:

• app_public_inputs — a map of all apps involved in the spell. App is a tuple of tag/identity/VK where:

  • tag is a single character representing the app type (n for NFTs, t for fungible tokens). tag can be anything, but n and t have special meaning (simple transfers of NFTs and tokens don’t need app contract proofs, so the recursive spell proof can be generated faster).
  • identity is a 32-byte array identifying the asset within this app.
  • VK is the verification key hash of the app implementing the logic of the asset: how it can be minted or burned, staked or used.
  • each app value is that app’s public input data (may be empty for simple transfers).

• tx.ins — a list of input UTXOs (txid:vout) to be spent by the transaction.

• tx.outs — a list of outputs (strings of charms) created by this spell. In each output, keys are app indexes (0, 1, 2, …) pointing to apps in app_public_inputs, and values are charm data for those apps.

• tx.coins — native coin outputs (Bitcoin sats or Cardano lovelace) for the resulting transaction outputs.
